40G QSFP+ DAC

40G QSFP+ TO QSFP+ DAC 1m

Rate40GReach1mWavelength-Interface-
Fiberland part number
FLD-QSFP+DAC-1M
Unit priceAsk Our Manager

Key Specifications

Select a specification to see how it affects model selection.

View complete table
Form TypeQSFP+

Check this recorded value against the target device and project requirements before quotation approval.

Technical Specifications

Filter the product record by the information needed for engineering or purchasing review.

14 specifications shown
Fiberland Part NumberFLD-QSFP+DAC-1MVendor NameFIBERLAND
Data Rate40GWavelength-
Reach1mForm TypeQSFP+
Optical Interface-DDM Support-
Commercial Temp.0~70℃Industrial Temp.-
Compatible BrandsCisco,Huawei,Nvidia...200+ brandsComplianceCE,FCC,ROHS,REACH
Warranty3 YearsMode-

Product Compatibility Mapping

Cross-reference the original manufacturer part number with the corresponding Fiberland part number before confirming the target device and firmware.

Search Full Compatibility Database
Verified cross-references16 manufacturer part numbersAcross 9 brands
Showing 8 of 16 verified matches

Swipe horizontally to view every field.

Original part numberBrandFiberland part numberProduct description
QSFP-H40G-CU1MCISCOFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
CAB-Q-Q-1MARISTAFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
QFX-QSFP-DAC-1MJUNIPERFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
740-038623JUNIPERFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
MC2206130-001NVIDIAFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
MC2210130-001NVIDIAFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
JH234AHPEFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.
R9F99AHPE ARUBAFLD-QSFP+DAC-1M40G QSFP+ to QSFP+ passive direct-attach copper cable, 1 m.

A part-number cross-reference is a model-selection starting point, not a blanket device guarantee. Final fit depends on the exact device, firmware or OS, target port and requested coding profile.
