100G QSFP28 DAC

100G QSFP28 Direct Attach Copper Cable 1m | FLD-Q28-DAC-1M | Fiberland

100G QSFP28 TO QSFP28 1m

Rate100GReach1mWavelength-Interface-
Fiberland part number
FLD-Q28-DAC-1M
Unit priceAsk Our Manager
Request a Quote Review Specifications
At a glance

Key Specifications

Select a specification to see how it affects model selection.

View complete table
Form TypeQSFP28

Check this recorded value against the target device and project requirements before quotation approval.

Model data

Technical Specifications

Filter the product record by the information needed for engineering or purchasing review.

14 specifications shown
Fiberland Part NumberFLD-Q28-DAC-1MVendor NameFIBERLAND
Data Rate100GWavelength-
Reach1mForm TypeQSFP28
Optical Interface-DDM Support-
Commercial Temp.0~70℃Industrial Temp.-
Compatible BrandsCisco,Huawei,Nvidia...200+ brandsComplianceCE,FCC,ROHS,REACH
Warranty3 YearsMode-
Compatible model reference

Product Compatibility Mapping

Cross-reference the original manufacturer part number with the corresponding Fiberland part number before confirming the target device and firmware.

Search Full Compatibility Database
Verified cross-references16 manufacturer part numbersAcross 9 brands
Showing 8 of 16 verified matches

Swipe horizontally to view every field.

Original part numberBrandFiberland part numberProduct description
QSFP-100G-CU1MCISCOFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
CAB-Q-Q-100G-1MARISTAFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
JNP-100G-DAC-1MJUNIPERFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
740-061000JUNIPERFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
MCP1600-C001NVIDIAFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
MCP1600-C001E30NNVIDIAFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
MCP1600-C001LZNVIDIAFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.
R0Z25AHPE ARUBAFLD-Q28-DAC-1M100G QSFP28 to QSFP28 passive direct-attach copper cable, 1 m.

A part-number cross-reference is a model-selection starting point, not a blanket device guarantee. Final fit depends on the exact device, firmware or OS, target port and requested coding profile.

Link and application reference

See Where This Product Fits in the Network

Review common data-center, DCI, campus, server and metro-network connections before confirming speed, reach, fiber type and connector.

Application planning

Optical Transceiver Application and Link Map

Compare representative network topologies and link paths to identify the appropriate product family for the intended deployment.

View full application diagram
Optical transceiver application diagram covering data center, DCI, campus, server and metro networks
Testing and quality reference

Review the Quality-Control and Test Flow

Follow the checkpoints used to verify materials, firmware, optical performance, temperature stability, compatibility and final inspection.

Testing and quality

Quality Control and Test Flow

Review the sequence from material verification and firmware programming through optical, temperature, compatibility and final QA inspection.

View full testing diagram
Quality control flow covering material, firmware, optical, temperature, compatibility and final QA checks
Product FAQ

Frequently Asked Questions

Answers to common compatibility, installation and troubleshooting questions.

Can different transceiver brands be used at opposite ends of a fiber link?

Yes. The transceivers do not normally need to be from the same manufacturer. Their Ethernet standard, wavelength, fiber type, lane configuration, reach, and other link requirements must be compatible.

What does an “unsupported transceiver” message mean?

It usually means the host device does not recognize or approve the identification information stored in the module. It does not necessarily indicate an optical failure.

Why does my compatible transceiver show low RX optical power?

Low receive power can result from excessive fiber loss, dirty connectors, damaged fiber, excessive link distance, incorrect wavelength pairing, or insufficient transmit power from the remote transceiver. Compare the measured RX power with the module's specified receiver range.

Why does a compatible transceiver work in one switch but not another?

Different switch models, hardware revisions, operating systems, and firmware versions may use different transceiver validation rules. A module compatible with one platform may require different coding for another.

How can I verify compatibility before ordering?

Check the network-device manufacturer and model, port type, required data rate, OEM transceiver reference if available, wavelength, reach, connector, fiber type, and software or firmware version when relevant.
