200G QSFP-DD, QSFP56 DAC

200G QSFP-DD TO QSFP-DD DAC 2m

Rate200GReach2mWavelength-Interface-
Fiberland part number
FLD-2Q56-DAC-2M
Unit priceAsk Our Manager
Request a Quote Review Specifications
At a glance

Key Specifications

Select a specification to see how it affects model selection.

View complete table
Form TypeQSFP56 ~ QSFP56

Check this recorded value against the target device and project requirements before quotation approval.

Model data

Technical Specifications

Filter the product record by the information needed for engineering or purchasing review.

14 specifications shown
Fiberland Part NumberFLD-2Q56-DAC-2MVendor NameFIBERLAND
Data Rate200GWavelength-
Reach2mForm TypeQSFP56 ~ QSFP56
Optical Interface-DDM Support-
Commercial Temp.0~70℃Industrial Temp.-
Compatible BrandsCisco,Huawei,Nvidia...200+ brandsComplianceCE,FCC,ROHS,REACH
Warranty3 YearsMode-
Compatible model reference

Product Compatibility Mapping

Cross-reference the original manufacturer part number with the corresponding Fiberland part number before confirming the target device and firmware.

Search Full Compatibility Database
Verified cross-references7 manufacturer part numbersAcross 6 brands
Showing 7 of 7 verified matches

Swipe horizontally to view every field.

Original part numberBrandFiberland part numberProduct description
QSFP-200-CU2MCISCOFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.
C-Q200-Q200-2MARISTAFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.
MCP1650-H002E26NVIDIAFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.
MCP1650-V002E26NVIDIAFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.
R5Z78AHPEFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.
QSFP56-200G-D-DAC-2MH3CFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.
4Z57A14185LENOVOFLD-2Q56-DAC-2M200G QSFP56 to QSFP56 passive direct-attach copper cable, 2 m.

A part-number cross-reference is a model-selection starting point, not a blanket device guarantee. Final fit depends on the exact device, firmware or OS, target port and requested coding profile.

Link and application reference

See Where This Product Fits in the Network

Review common data-center, DCI, campus, server and metro-network connections before confirming speed, reach, fiber type and connector.

Application planning

Optical Transceiver Application and Link Map

Compare representative network topologies and link paths to identify the appropriate product family for the intended deployment.

View full application diagram
Optical transceiver application diagram covering data center, DCI, campus, server and metro networks
Testing and quality reference

Review the Quality-Control and Test Flow

Follow the checkpoints used to verify materials, firmware, optical performance, temperature stability, compatibility and final inspection.

Testing and quality

Quality Control and Test Flow

Review the sequence from material verification and firmware programming through optical, temperature, compatibility and final QA inspection.

View full testing diagram
Quality control flow covering material, firmware, optical, temperature, compatibility and final QA checks
Product FAQ

Frequently Asked Questions

Answers to common compatibility, installation and troubleshooting questions.

Will DOM values appear correctly on third-party transceivers?

With a properly compatible module and supported host platform, DOM/DDM values should normally be accessible through the network equipment's management interface.

What does an “unsupported transceiver” message mean?

It usually means the host device does not recognize or approve the identification information stored in the module. It does not necessarily indicate an optical failure.

What information should I provide when requesting technical support for a compatible transceiver?

Provide the transceiver part number, corresponding OEM part number, switch or router brand and exact model, operating system or firmware version, port number and speed, error messages, DDM/DOM readings, and information about the transceiver and equipment at the opposite end of the link.

Why does replacing an OEM transceiver with a compatible transceiver result in no link?

First verify that the compatible replacement matches the OEM module's form factor, data rate, wavelength, reach, fiber type, connector, and interface standard. Then confirm that it has the correct compatibility coding for the host platform.

Why is the transceiver recognized but DDM/DOM information is missing?

The module may be recognized while diagnostic monitoring is not fully supported by the host platform or compatibility profile. Check whether both the transceiver and network device support DDM/DOM for that interface.
