Select a specification to see how it affects model selection.
Check this recorded value against the target device and project requirements before quotation approval.
Filter the product record by the information needed for engineering or purchasing review.
| Vendor Name | Fiberland | Form Type | X2 |
|---|---|---|---|
| Data Rate | 10Gbps | Wavelength | 1550NM |
| Reach | 80km | Optical Interface | Duplex SC |
| Media Type | SM | DDM Support | YES |
| Commercial Temp. | 0~70℃ | Industrial Temp. | N/A |
| Compatible Brands | Cisco | Certificates | CE,FCC,ROHS,REACH |
| HS Code | 8517706000 | Warranty | 3 Years |
Cross-reference the original manufacturer part number with the corresponding Fiberland part number before confirming the target device and firmware.
Send the target device brand, model, firmware or OS and port details for an exact compatibility review.
A part-number cross-reference is a model-selection starting point, not a blanket device guarantee. Final fit depends on the exact device, firmware or OS, target port and requested coding profile.
Review common data-center, DCI, campus, server and metro-network connections before confirming speed, reach, fiber type and connector.
Compare representative network topologies and link paths to identify the appropriate product family for the intended deployment.
Follow the checkpoints used to verify materials, firmware, optical performance, temperature stability, compatibility and final inspection.
Review the sequence from material verification and firmware programming through optical, temperature, compatibility and final QA inspection.
Answers to common compatibility, installation and troubleshooting questions.
Most SFP-family, QSFP-family, and similar pluggable transceivers are designed for hot-pluggable operation according to the applicable interface specification. Host-equipment procedures should still be followed.
No. Each transceiver generally needs to be compatible with the equipment in which it is installed. For example, one end may be coded for one switch brand and the other end for another.
Possible causes include incorrect fiber type, wavelength mismatch, polarity, dirty connectors, excessive optical loss, incompatible link partners, FEC settings, port configuration, or compatibility issues.
Check whether the port is administratively enabled and whether the host has disabled the transmitter because of an unsupported-module condition or configuration issue. If the module is correctly recognized and enabled, further hardware testing may be required.
The module may be recognized while diagnostic monitoring is not fully supported by the host platform or compatibility profile. Check whether both the transceiver and network device support DDM/DOM for that interface.
Move from model selection to internal approval with the documents, compatibility checks and verification paths buyers use most.
01Technical filesFind model-level specifications, drawings and selection documents before internal review.
Find datasheets
02Device fitReview device, firmware and coding fit before specifying a module for your network.
Check compatibility
03VerificationSee optical, functional and pre-shipment checks used to verify product performance.
Review testing
04Project approvalReview certification routes and request supporting documents for project approval.
View documents
